Submersible Pump Cables
Approvals︰CE
File No.︰IEC 60227、60364-5-52、BS 7671
Submersible pump cables and wires supply power to submersible underwater pumps. These waterproof cables operate underwater for extended periods and resist physical pressure, abrasion, oil, chemicals, and weather conditions. They are great for deep well installations, offering flexibility to run through tight spaces and deliver power up to depths of 100 meters. These cables are available with a sturdy outer jacket for enhanced protection. Resistant to wear and tear, these cables provide a long service life even in harsh conditions, reducing the need for frequent replacements or repairs. Common applications include groundwater pumping, sewage treatment plants, seawater handling, irrigation systems, firefighting, and offshore drilling.
They conform to UL 44, IEC 60227, BS 6500, and ISI 694 standards. The cable follows the UL specification of a 90 °C type RHW-2 cable. Packaging and length can be tailored to customer needs. Whether you’re powering a groundwater pump, managing a sewage treatment plant, or handling offshore drilling operations, CKW’s submersible pump cables are the reliable choice for your power supply needs. Based in Taiwan, CKW is a professional manufacturer of Submersible cables and wires. Please feel free to contact us for further details.
(1) Safety and Strict QC management, Made in Taiwan.
(2) Excellent resistance to water, moisture, abrasion, grease and oil.
(3) Generally conforming to:UL 44, IEC 60227, BS 6500, ISI 694.
(4) The package and length can be modified according to the requirements of customers.
- Operating Temperature：-40 °C ~90°C
- Temperature Rating：60 °C, 75°C, 90°C
- Voltage Rating：600 volts
- PVC 3 Cord Flat Submersible Pump Cables (Without Ground)：
| Size(AWG/NO. of conductors) | Nos and Dia. of wire (Nos.X mm) | Core Dia.(mm) | Nominal Sheath Thickness (mm.) | Cable Overall Dimension(mm) |
| 14/3 | 41 X 0.254 | 3.60 | 1.15 | 13.30 X 6.20 |
| 12/3 | 65 X 0.254 | 4.30 | 1.15 | 15.60 X 7.00 |
| 10/3 | 105 X 0.254 | 5.10 | 1.15 | 17.70 X 7.40 |
| 8/3 | 168 X 0.254 | 6.30 | 1.40 | 22.30 X 9.30 |
| 6/3 | 226 X 0.254 | 7.60 | 1.40 | 26.30 X 10.80 |
| 4/3 | 420 X 0.254 | 9.90 | 2.00 | 32.30 X 13.10 |
| 2/3 | 665 X 0.254 | 11.10 | 2.00 | 35.90 X 14.30 |
NoteThe number of wires of conductor and wire diameter are nominal, they should satisfy the requirements of conductor resistance of IEC 60228 /DIN VDE 0295 / IS 8130 / BS 6360.
- PVC 4 Cord Flat Submersible Pump Cables (Without Ground)：
| Size(AWG/NO. of conductors) | Nos and Dia. of wire (Nos.X mm) | Ground Conductor Size(AWG) | Core Dia. (mm) | Nominal (mm) | Cable Overall Dimension(mm) |
| 14/4 | 41 X 0.254 | 14 | 3.85 | 1.15 | 18.00 X 6.50 |
| 12/4 | 65 X 0.254 | 12 | 4.50 | 1.15 | 21.00 X 7.60 |
| 10/4 | 105 X 0.254 | 10 | 5.30 | 1.15 | 24.30 X 7.90 |
| 8/4 | 168 X 0.254 | 10 | 6.50 | 1.40 | 29.70 X 9.90 |
| 6/4 | 226 X 0.254 | 8 | 8.00 | 2.00 | 36.00 X 11.80 |
| 4/4 | 420 X 0.254 | 8 | 10.10 | 2.00 | 45.10 X 14.70 |
| 2/4 | 665 X 0.254 | 6 | 11.30 | 2.20 | 50.10 X 16.20 |
NoteThe number of wires of conductor and wire diameter are nominal, they should satisfy the requirements of conductor resistance of IEC 60228 /DIN VDE 0295 / IS 8130 / BS 6360.
Submersible pump cables can be used in different kinds of applications, including sewage treatment plants, seawater handling, groundwater pumping, fire fighting (since it is flame retardant cable), borehole drilling, water well and deep well drilling, offshore drilling rigs, artificial lifts, mine dewatering, irrigation systems, and water supply systems.
